Home > KVM -> KVM Matrix Switchers -> Cat-5 -> 2X8 -> ATEN -> KH2508A 2-Console 8-Port Cat 5 KVM PS/2-USB Switch with Daisy-Chain Port


2-Console 8-Port Cat 5 KVM PS/2-USB Switch with Daisy-Chain Port

Satisfaction Guaranteed!
Part #: KH2508A
Your Price: $675.00
0 out of 5 based on 0 ratings.

The KH2508A KVM switch from ATEN is a 8-Port, 2 Users over CAT 5, PS/2-USB control unit that allows IT administrators to access and control multiple computers from two PS/2 or USB KVM consoles (one bus). Operators working at up to two consoles can independently and simultaneously take control of up to 8 computers. By daisy chaining up to 31 additional switches, as many as 256 computers can be controlled from the original KVM consoles. This switch has been designed with unique and powerful features that enable administrators to manage their entire server room and data center devices easily and conveniently. It is compatible with PC, Mac, Sun and Serial Devices and provides quality video resolutions up to 1600x1200 up to 132' in length. This unit also provides Broadcast Mode which sends commands from the console to all computers, allowing users to perform operations such as software installations, upgrades, shutdown, etc..

For example, the advanced Adapter ID feature stores the Adapter Cable's configuration information – such as its ID, port name, OS, keyboard language, etc. This feature allows administrators to relocate servers to different ports without having to reconfigure the adapters . Other advances found with these switches includes enhanced video quality – extending the distance to the servers to up to 164' at a resolution of 1280 x 1024 using a KVM Adapter Cable KA7000 series (not included). A KH2508A installation provides one of the best, and most economical, solutions ATEN offers to the SMB market. There is no better way to save time, space, and money than with a KH2508A KVM switch.

Additional Features of the KH2508A Include:

  • Diversified port operation mode enables flexible computer management – Occupy, Exclusive and share modes
  • Three port selection methods: Manual (via front panel pushbuttons), Hotkey, and multi-language OSD (On Screen Display)
  • Multiplatform support – PC, Mac, Sun, and serial
  • Multiple User Accounts -Supports up to 10 user and 1 administrator accounts
  • Two-Level Password Security- Supports one administrator and ten user profiles. Strong password protection prevents unauthorized accessing to the installation
  • Auto Scan mode enables continuous monitoring of user-selected computers
  • Console conversion – any type of KVM console can control any type of computer; mixed combinations (PS/2&USB) supported on both the KVM console and computer sides
  • Computer Connections: 8 Direct, Up to 128 (via Daisy-Chain)
  • Port Selection: OSD, HotKey, Pushbutton
  • Console Port Connectors: 4x USB Type A, 4x 6-pin Mini-DIN, 2x VGA
  • KVM Port Connectors: 8x RJ-45
  • Daisy Chain Ports: DB-25 Male, DB-25 Female
  • Switches: 8x Port Selection, 2x Console Selection, Reset, Firmware Upgrade, Power
  • LED Indicators: 8x Online, 8x Selected, 2x Console, Power, Station ID 1x 7-segment LED
  • Emulation: USB/Keyboard: PS/2, USB
  • Video Resolution: 1600x1200 up to 131', 1280x1024 up to 164'
  • Scan Interval: 1-255 Seconds
  • Maximum Input Power Rating: 100-240V AC, 50/60 Hz, 1A
  • Power Consumption: 120V/7.2W, 230V/8.6W
  • Dimensions (LxWxH): 17.21 x 6.13 x 1.73
  • Weight: 6.19 lbs
  • Included Accessories: Firmware Upgrade Cable, Power Cord, Grounding Wire, Rack Mount Kit, Foot Pad Set (4 pcs.), User Manual, Quick Start Guide
  • Warranty: 3 Years
