AVPro Edge AC-AXION-OUT-HDBT
AXION HDBaseT Output Card
-Chad R.
Description
The AC-AXION-OUT-HDBT is an output card for the AC-AXION-X modular matrix chassis. It does not work on its own. The chassis has eight output slots, and this card adds two HDBaseT outputs. Output A also has a mirrored HDMI port for a local display or other device.
HDBaseT signals pass uncompressed up to 10.2 Gbps. Higher-bandwidth signals, up to 18 Gbps, need AVPro Edge's Invisible Compression Technology (ICT), which is the default mode. Thus not having ICT, signals above 10.2 Gbps will not pass. The alternative scaling setting converts 4K to 1080p, changing pixel density but not frame rate or color space.
Distance depends on the receiver. The AXION manual lists 70 m at 4K60 4:4:4 with HDR, and 100 m at 1080p, using the AC-EX70-444-RNE or AC-EX70-SC2-R. Other AVPro Edge receivers have lower ratings.
The manual recommends Cat 6 or better with standard RJ45 ends. LINK and STATUS lights help with troubleshooting. Each HDBaseT output has a Bitstream Audio setting, on by default. The chassis itself offers IR, RS-232 and LAN control and a web interface, along with independent audio matrixing. Lower-rated receivers include the AC-EX70-UHD-R, at 40 m for 4K30 4:4:4 or 4K60 4:2:0.
Key Features
- Two HDBaseT outputs
- One mirrored HDMI port on Output A
- 18 Gbps with ICT; 10.2 Gbps uncompressed
- 4K-to-1080p scaling option
- Bitstream audio setting on each output
- Uses one AXION-X output slot
Typical Applications
Suits commercial and residential matrix systems with displays far from the rack, such as sports bars, conference facilities and large homes. For displays close by, compare the AC-AXION-OUT-AUHD.
Frequently Asked Questions
Can I use non-AVPro HDBaseT receivers?
They may work, but AVPro Edge says ICT will not. That limits their use with signals above 10.2 Gbps.
How is it different from the HDBT-L card?
The AC-AXION-OUT-HDBT-L is a limited version, without CEC or over-the-air firmware updates.
Does the card have audio extraction ports?
No. Extracted audio comes from the Toslink and balanced 5-pin ports on the matrix, which can bind to an input or output, or run as an independent matrix.
Does it power the receivers?
The card documentation does not specify Power over HDBaseT, so plan on powering receivers locally unless you confirm otherwise.
