Kramer AV KDock-3
USB-C Hub Multiport Adapter with HDMI, DisplayPort, 4k, Ethernet

Description

The Kramer KDock-3 is a USB-C hub multiport adapter specially designed to support mobile devices and is an ideal accessory for MacBook, laptops equipped with USB Type-C, mobile phones, and tablets. KDock-3 enables you to connect your USB-C device to HDMI and DisplayPort video outputs, 2 USB 3.0 ports, an Ethernet port, SD card port and USB−C data and charging pass−through.

Note: Video output for smartphones is supported only for smartphones that support DisplayPort Alt mode through USB-C.

Specifications

• USB C data port and charging pass through
• Inputs: 1 USB: On a USB Type C male connector
• Outputs: 1 HDMI: On a female HDMI connector, 1 DisplayPort: On a female DisplayPort connector
• Ports: 2 USB 3.0/2.0: On female USB type A connectors, 1 Ethernet: On an RJ 45 connector, 1 USB 3.0: On a female USB type C connector for data and charging, SD: On an SD card port
• Max Resolution: 3840x2160P@30Hz (with one display connected)
• Max Resolution: 1920x1080P@60Hz (with two displays connected)
• Max Data Rate (HDMI/DP output): 10.2Gbps (3.4Gbps per graphic channel)
• Multiple Video Output Support: Via MST (Multi Stream Transport) technology
• Content Protection (HDMI output): HDCP 1.4
• Max Data Rate: 1000M (Gigabit)/100M/10M
• Includes: Wake on LAN (WoL), single Mac address, PXE boot
• USB 3.0 Data Transmission Speed (USB 3.0 & USB-C): Up to 5.0Gbps
• Delivery: 100W
• USB Charging: BC1.2 (5V 1.5A)
• USB Limited Current when Connected to Power via female USB-C port: 1.9A
• USB Limited Current when Not Connected to Power via female USB-C port: 1A

Downloads

• Kramer AV KDock-3 Specifications (PDF)
• Kramer AV KDock-3 Manual (PDF)
• Kramer AV KDock Comparison Chart (PDF)
