Vocia VO-4
Vocia Vocia networked audio output expansion device with 4 line-level output channels

Description

The VO-4 is a networked audio output expansion device allowing the user to add four line-level output channels to a Vocia system. The VO-4 accepts four channels of digital audio input via CobraNet and provides four line-level analog audio outputs. The VO-4 features embedded DSP and on-board memory to process and store all device-specific configuration information locally and includes comprehensive fixed-chain digital signal processing.

Specifications

• Dual PoE capable with alternate powering from auxiliary 24 volt DC supply (dual inputs)
• LED status and fault indication:
  Chassis Fault, Activity and Status
  • PoE Power
  • Aux Power
  • Output Channel Amp Fault, Activity and Signal Present
• Four Page Active Relays, Control Inputs, and Control Outputs
• Speaker line monitoring and ambient noise compensation using ELD-1 and ANC-1
• Software-configurable signal processing including volume control, filters, compressor/limiting, delay, speaker equalization, and output level
• CobraNet audio/control with dynamic use of available bundles over single Ethernet cable
• Dual CobraNet ports for redundancy
• Rack mountable (1RU)
• Rotary switches for device identification
• IP30 Compliant
• CE marked and RoHS compliant
• 5-year warranty
• Compliant with the US Trade Agreement Act (TAA)

Downloads

• Vocia VO-4 Specifications (PDF)
