AtlasIED IED1516LI
16 Input Logic Module
Part #: IED1516LI
Satisfaction Guaranteed!
MSRP: $1,297.99
Our Price:
$1,038.99
Top IED1516LI Specifications
- Input Voltage: 48VDC (PoE Compliant with IEEE 802.3af)
- Power: 3-Watts Max
- Inputs: 8-pin Phoenix, 3.81 mm spacing
- Operating Temperature Range: -22 degrees F - +149 degrees F (-30 degrees C - +65 degrees C)
"Quick and easy to find what I was looking for."
-Brandon K.
-Brandon K.
Contact a product specialist!
Proudly supporting our customers since 2008
Description
The 1516LI is a network logic input device used to interface with an IED GLOBALCOM announcement control system. It provides 16 optically-isolated inputs that can be driven using dry contact closures or 0 to 50VDC logic signals. A green LED is provided above each input that illuminates when activated. The announcement controller is configured using the GLOBALCOM System Management Center software where logic inputs can be used to launch announcements, pre-recorded messages, events, or fault reports.
Specifications
- Height: 7.01" (17.81 cm)
- Width: 3.50" (8.90 cm)
- Depth: 2.00" (5.08 cm)
- Weight: 7.3 oz (206.9g)
