Altinex UT240-610
POWER + 10 PORTS + AV DISTRIBUTION PLATE, 1U

Description

The UT240-610 is a 1U high power/charging rack-mounted plate with customizable ports. The plate offers three power sockets with a total capacity of 12A. Two are located on the front and one on the back with a single power cord. The UT240-610 features two USB charging ports that are easily set up using the included dual-output USB charger (5V, total 3.4A) and provided cables. Eight customizable ports support XLR connectors or Keystone snap-in adapters. Also included are a repositionable labeling system with 20 blank labels, and 10-32 screws and washers for easy rack mounting.

Specifications

• Ten (10) Keystone type ports
• All ports are XLR compatible
• Eight blank covers for unused ports
• Two port USB charger with US plug
• One 2.0 charging USB A/A Keystone couplers
• One 2.0 charging USB C/A Keystone cable
• One USB A-M to USB A-M (1 ft.) cable
• Custom labels available with additional cost
• Rack mounting hardware included
• UL listed

Downloads

• UT240-600 User Guide (PDF)
