Lew Electric SWB-6-A

Rectangle Six Power Floor Box w/ 6 Screw Plugs - Aluminum

In Stock!
Part #: SWB-6-A
Regular Price: $197.08
Instant Savings: -$39.42
Quantity: $157.66
0 out of 5 based on 0 ratings.

The Lew Electric SWB-6-A is a rectangular floor box that holds (6) 15A tamper resistant power outlets, the top aluminum plate features six screw plugs. The box meets NEMA WD1-1983 heavy duty requirement for display receptacles, the box and outlets are UL listed. The box features a water tight assembly and includes a neoprene gasket. The box is adjustable and can accommodate any thickness floor up to 3/4".

***Includes 4 port keystone plate in case you want to replace one of the outlets***

To install use the included back box, there are sixteen 3/4" conduit knockouts to bring your wire into.  The box may be attached directly to a sub floor or routed into finished floor. Screws are included to attach the box to the plate.

The Lew Electric SWB-6-A is an economical solution when you need three duplex powers that is easy to install and functions perfectly in a small compact box.

  • Cover plate: 1/8" thick brass
  • Six 15A tamper resistant outlets
  • Six screw plug openings
  • Box dimensions: 7" X 5"
  • Depth: 4.01"
  • Water tight assembly
  • Outlet UL listing # 498
  • Outlet meets NEMA WD1-1983 heavy-duty requirement for display receptacle code
  • Box UL listing # 729A (File # E333616)
  • Cutout max dimensions: 6" x 3 1/2"
  • Includes 4 port keystone plate, back box, 1/16" neoprene gasket, and brass installation screws
  • Can accommodate any thickness floor up to 3/4"
  • Warranty: 6 months
