8x8 HDBaseT Matrix Switcher with 4K Resolution - 8 Receivers
Manufacturer SKU: MX-0808-KIT-v2
Our Price: $3,888.00
Top MX-0808-KIT Specifications
- 8x8 matrix with 8 HDBaseT zones and 4 mirrored HDMI outputs
- SmartEDID dynamically detects display/source capabilities and automatically outputs the highest possible resolution
- Additional EDID management through DIP switches for global setting or via WebUI for independent management
- Embedded WebUI enables simple source switching and installer set-up & configuration
"Excellent experience - thank you for all your help"
Contact a product specialist!
1-888-999-3759 | Chat | Email
Proudly supporting our customers since 2008
The MX-0808-KIT-v2 offers the transmissions of 4K UHD up to 35m/115ft, and up to 8 HDBaseT outputs with included receivers. Additionally, it is equipped with 4 mirrored outputs, which can be paired with any of our HAOC hybrid optical HDMI cables to connect to 4 additional screens. The fitting are 4 balanced analog audio outputs 2ch support to connect to ceiling/over–hanging speakers or to an audio amplifier. Lastly, enjoy the including CEC triggering, A/V mute and standby mode to extend the life of the matrix during downtime.
- WebUI with full EDID management to copy EDID from connected devices
- Independent user control interface with separate password-protected installer settings
- Personalize switching interface with source and output labelling
- Hide unused I/O for cleaner appearance and navigation
- API triggered standby mode puts unit into low power state during downtime
- 2-way IR for far-end device control from control system or source control from a zone.
- US, UK, EU & AU Power cables included
- Compact 1U chassis with adjustable depth rack mounting brackets included
In the Box
- 1x MX-0808-KIT Matrix
- 8x MX-KIT-RX Receivers
- 1x AC Power Cord (UK/US/EU)
- 1 x Remote (Battery not included)
- 8x IR Emitters
- 8x IR Receivers
- 2x Matrix Mounting Brackets (2 per RX)
- 1x Quickstart Guide
