Christie DHD630-GS
HD 6,125 Lumen Laser Projector

Description

Christie's DHD630-GS is a high-resolution laser projector. It boasts 20,000 hours of operation, as well as 1DLP technology. With a 4,000,000 to 1 full contrast ratio courtesy of Christie's RealBlack technology, the images from the projector will be vibrant and almost pop off the screen with their detail.

Other key features of this projector include the following:

• Powerful laser diodes for 6,125 ISO lumens of light output
• Compatible with all GS Series lenses, including the new Ultra Short Throw (UST) lens.
• Compact and light – One of the smallest and lightest projectors in its brightness class.

Specifications

• Remote in: 3.5mm stereo female (provides serial communications and power)
• HDBaseT (RJ45 x 1)
• RJ45 x 1 (Control over wired network connection)
• 3D Signal Inputs
• HDMI 1.4, HDBaseT - Frame Packed, Top/Bottom, Side by side
• Up to 120Hz output
• Does not support frame sequential 3D
• 3D Sync Out (BNC) - for genlocking projectors or controlling emitters
• Brightness
• ISO: 6,125
• Center: 5,400
• ANSI: 5,400
• Color Wheel: 4 Segment (RGBY) - 2X or 3X speed
• Contrast (Nominal)
• Full On/Off (Christie Real Black Enabled): 4,000,000:1
• Dynamic Contrast: 6,000:1
• Full On/Off (Christie Real Black Disabled): 1,200:1
• ANSI: 250:1
• Display: 1 x 0.65" DMD
• Resolution: 1920 x 1080 (2,073,600 pixels) 16:9
• Illumination Type: High efficiency blue laser phosphor
• Illumination Lifetime: 20,000 hours
• Signals
• HDTV formats VGA through to WUXGA (1920 x 1200)
• Horizontal and vertical scaling while maintaining aspect ratio, all inputs
• Pixel clock: 162MHz
• Scan rates
• Horizontal: 15 kHz to 91 kHz
• Vertical: 24 Hz to 120 Hz
• Signal Outputs
• HDMI x 1
• Control and Networking
• RS232 In
• Control via HDBaseT
• Ethernet (10/100) RJ45
• Built-in backlit keypad
• IR remote
• Wired remote control (3.5mm stereo)
• Standard Accessories
• IR Remote w/ wired remote jack (wire not included)
• AC Line cords for projector
• User Manual
• Optional Accessories
• Christie One Mount
• One Mount Extender Rod
• One Mount Rigging Kit (used with One Mount, One Mount Plus and/or One Mount Extender Rod)
• Cable cover GS white
• Lens Mount
• Boresight adjustable
• Motorized horizontal and vertical lens offset
• Motorized zoom and focus adjustment
• Lens Options
• Lens 0.75-0.95 Zoom G/GS
• Lens 0.95-1.22 Zoom G/GS
• Lens Zm Std G/599-GS 1.22-1.53
• Lens Zm Std G/555-GS 1.22-1.52
• Lens Zm HP G/GS 1.22-1.52
• Lens 1.52-2.89 Zoom G/GS
• Lens 2.9-5.50:1 Zoom G/GS
• Lens UST 0.36 Ultra short throw lens
• Power Requirements
• Operating Voltage - Normal: 100-240 VAC @ 50/60 Hz (w/ 15A fuse)
• Power Consumption - Normal Mode: 650W
• Operating Current - Normal Mode: 9.5A (100V-240V)
• Dissipation: 97.5W
• Audible Noise (typical 2x Wheel Speed): 34dB(A) Eco2 Mode / 36dB(A) Normal Mode
• Physical Dimensions
• 19.90 x 17.95 x 7.60" without feet or lens
• Physical Weight: 39.94lbs (15.85kg) without lens
• Shipping Dimensions
• 24.65 x 23.43 x 13.74"
• Shipping Weight: 47.06lb (21.35kg)
• Operating Environment: 0 to 40 C (32 to 104 F), 0-2500 ft altitude / 0 to 30 C (32 to 86 F), 5,000-10,000 ft altitude
• Humidity: 0 - 85% non-condensing
• Regulatory
• Contact Christie for timing of certifications: UL/CSA/IEC 60950-1, FCC Class A, CE, FDA, CCC, KC, PSE, CU, SABS, BIS, VCCI, RCM, Ukr, TER, SASO
• This product conforms to all relevant European directives, standards, safety, health and environmental concerns
• RoHS, REACH, WEEE
• Limited warranty
• 3 years parts and labor on the projector
• 3 years or 15,000 hours parts and labor on the illumination system*
• Contact an authorized Christie representative for full details of limited warranty

Downloads

• Christie DHD630-GS Specifications (PDF)
• Christie DHD630-GS Manual (PDF)
