FOR-A FC-ONE
Flicker Corrector 3G/HD-SDI I/O, Process Amplifier, Color Corrector

Part #: FC-ONE
Satisfaction Guaranteed!
Need a price or product info? Complete and submit the below
Quantity
Email
Name
Top FC-ONE Specifications
  • Video Format
  • 1080/59.94i,1`080/50i, 1080/59.94p (level A-B), 1080/50p (Level A/b), 720/59.94p, 720/50p
  • Video Input
  • 3G-SDI (Level A/B): 3.0 Gbps, HD-SDI: 1.5 Gbps, 75 Ohms, BNC x 4
"Quick and easy to find what I was looking for."
-Brandon K.
Contact a product specialist!
Proudly supporting our customers since 2008

Description

FOR-A's FC-ONE flicker corrector, color corrector, and process amplifier is plug-and-play device that suppresses flicker from high-speed cameras and poor lighting conditions.

Key Features:

  • Corrects video flicker
  • 1 input/output standard
  • Maintains image brightness and detail
  • Ideal for live or recorded media
  • Compact 1U enclosure
  • Control via network or software GUI
  • Supports 3G/HD-SDI input and output

Specifications

  • Video Output
  • 3G-SDI (Level A/B): 3.0 Gbps, Hd_SDI: 1.5 Gbps, 75 Ohms, BNC x 4
  • Video I/O Processing
  • Standard: Processes the selected input (1 of 4) as one line for distribution to four manually assigned outputs
  • Processing
  • 4:2:2 digital component
  • Quantization
  • 3G/HD-SDI: 10-bit
  • Genlock Input
  • BB: NTSC: 0.429 Vp-p/PAL: 0.45 Vp-p or Tri-level Sync: 0.6 Vp-p, 75 Ohms, loop-through, BNC x 1 (terminates with 75 Ohms terminator)
  • Synchronizer Modes
  • Reference mode, input mode
  • Video Delay
  • 2 frames (FS function)
  • Video Functions
  • Process amplifier, color corrector
  • Process Amplifier
  • Video Level: 0.0% to 200%
  • Chroma Level: 0.0% to 200%
  • Black Level: -20% to 100%
  • Hue: -179.8 degrees to +180 degrees
  • Video Clip
  • YPbPr, RGB
  • Color Correction
  • Balance, Differential, Sepia
  • Power Consumption
  • 100 V AC to 240 V AC +/- 1-%
  • Dimensions (W x H x D)
  • 430mm x 44mm x 400mm
  • Weight
  • 7 kg
  • Accessories
  • CD-ROM, AC cord, mounting brackets
