WyreStorm RX-70-4K-SCL
4K HDBaseT HDMI Receiver, Up/Down Scaling, Dual Ethernet Port

Part #: RX-70-4K-SCL
Satisfaction Guaranteed!
MSRP: $1,248.75
Our Price: $999.00
Free Shipping* | 30 Day Returns* | Authorized Dealer
Coupon
Click for $50 Off!
Top RX-70-4K-SCL Specifications
  • Inputs: HDBaseT (RJ-45)
  • Outputs: HDMI, S/PDIF Out Coaxial Digital, Audio Out 3-pin Phoenix Connector
  • Video Resolutions: Up to 4K/60 4:2:0 at 328' over Cat6a/7' Bandwidth: HDCP 2.2 Compliant
  • Audio Formats S/PDIF: 2ch PCM / Multichannel: Up to 5.1 DTS and Dolby Digital
"Super fast responses, super fast direct support. Quick shipping. Best prices out there when buying in bulk. Thank you!"
-Chad R.
Contact a product specialist!
Proudly supporting our customers since 2008

Description

The WyreStorm RX-70-4K-SCL is a Class A 4K HDBaseT Receiver with a built in scaler which offers uncompressed 4K or UHD video @60Hz with Ethernet, RS-232 and Bidirectional IR. Added to this is the ability to send ARC signals back to a compatible matrix, audio breakout ports for connection to a local amplifier and CEC control which can either be triggered automatically or via the Telnet API. It is suitable for any application where high quality video scaling of 4K content is required due to an installation using a mixture of 2K and 4K displays.

Key Features of the RX-70-4K-SCL Include:

  • HDBaseT 5Play
  • Resolves issue with mixing 4K & 2K screens in an installation by down-scaling UHD 4K content to 1080/720p
  • Also up-scales any incoming content to 4K/60 4:4:4 8-Bit
  • Receives 4K UHD @60Hz 4:2:0 or HDR @24Hz at 70m/230ft and 1080p content at 328ft
  • S/PDIF and Analog audio breakout
  • Scaling, ARC, CEC & Audio Out controllable via HDBaseT/Ethernet link by Telnet
  • Dual Ethernet ports
  • Bidirectional IR & RS-232
  • HDCP 2.2 compliant

Specifications

  • Audio Formats HDMI: 2ch PCM | Multichannel: LPCM and Up to DTS-X and Dolby Atmos
  • Color Depth 1080p: 16bit | 4K UHD: 8bit | HDR @24p: 10bit BT.2020
  • Maximum Pixel Clock: 297MHz
  • Power Supply: 12V DC 3A
  • Max Power Consumption: 16.4W
  • Dimensions (HxWxD): 1" x 9.23" x 5.65: Weight: 1.45 lbs
  • Included Accessories: 12V DC 3A Power Supply, AC Cable, 2x 3-pin Phoenix Connector, IR Emitter, IR Receiver, USB to 3-pin RS-232 Port Adapter Cable, 2x Mounting Brackets, Quickstart Guide
  • Warranty: 5 Years
  • Communication and Control
  • HDMI: HDCP 2.2 | EDID (Configurable) | CEC | DVI-D supported with adapter (not included)
  • HDBaseT: HDMI | HDCP 2.2 | EDID (Configurable) | CEC | Bidirectional IR, RS-232, and Ethernet
  • Ethernet: 2x 8-pin RJ-45 female | 10/100 Mbps auto-negotiating | Bidirectional over HDBaseT IR: 1x IR TX 3.5mm (1/8in) TS Mono | 1x IR RX 3.5mm (1/8in) TRS Stereo | Transmitted over HDBaseT
  • RS-232: 1x 3-pin Phoenix Connector | Bidirectional over HDBaseT when used with H2X matrix
  • Audio Return Channel (ARC): Returns audio from displays built-in applications via ARC HDMI Input over HDBaseT
