Kramer FC-174
4-Channel HDMI 4K60 4:4:4/4:2:0 Converter with HDCP 1.4 & 2.2

Manufacturer SKU: 40-00076790
Satisfaction Guaranteed!
MSRP: $715.00
Our Price: $572.00
Free Shipping* | 30 Day Returns* | Authorized Dealer
Coupon
Click for $20 Off!
Top FC-174 Specifications
  • Inputs
  • 4 HDMI: On female HDMI connectors
  • Outputs
  • 4 HDMI: On female HDMI connectors
"Very convenient and great customer support."
-Lynn Y.
Contact a product specialist!
Proudly supporting our customers since 2008

Description

Kramer's FC-174 is a versatile HDMI 4K@60Hz (4:4:4/4:2:0) multi-channel converter tool. FC-174 converts up to four inputs/outputs from 4:4:4 to 4:2:0 color sampling and offers EDID management via a user-friendly software application. It also enables inter-operability between HDCP 2.2 and HDCP 1.4 systems for up to 4 HDMI sources simultaneously. FC-174 acts as an HDMI extender that equalizes and re-clocks TMDS data before re-transmitting, increasing the HDMI cable range from each of the 4 outputs.

Features

  • Max. Resolution – 4K@60Hz (4:4:4)
  • HDMI Compliance – HDMI 1.4 and 2.0
  • HDCP Compliance – HDCP 1.4 and 2.2
  • Kramer Equalization and re-Klocking Technology – Rebuilds the digital signal integrity to travel longer distances
  • Selectable EDID Options – Default (internal), external (sink) or user-defined
  • Independent Pattern Generators on Each Output – Displays a variety of patterns and resolutions
  • User Friendly Control – OSD menu via front-panel buttons
  • Convenient USB Port – For application control and upgrading firmware

Specifications

  • Ports
  • 1 USB: On a female USB type-A connector for firmware upgrade
  • 1 RS-232: On a 9-pin D-sub connector for EDID management via a software application
  • Video
  • HDMI Standards Compliance: 1.4 and 2.0
  • HDCP Standards Compliance: 1.4 and 2.2
  • Max. Resolution: 4K@60Hz (4:4:4)
  • User Interface
  • Control: OSD menu via front panel buttons
  • Indicators: ON LED
  • Power
  • Source: 5V DC
  • Consumption: 1.8A
  • Environmental Conditions
  • Operating Temperature: 32 to 104 F
  • Storage Temperature: -40 to 158 F
  • Humidity: 10% to 90%, RHL non-condensing
  • Accessories
  • Included: Power adapter, bracket set
  • Optional: RK-T2B 19" rack adapter
  • Dimensions
  • 7.38" x 4.53" x 1.00" W, D, H
  • Weight
  • 1.0lbs approx.
  • Shipping Dimensions
  • 13.58" x 6.50" x 2.05" W, D, H
  • Shipping Weight
  • 2.2lbs approx.
