Aurora VLX-TCW2V-C-B
4K Streaming Transceiver Wall Plate with HDMI I/O, VGA Input

Part #: VLX-TCW2V-C-B
Satisfaction Guaranteed!
MSRP: $1,398.00
Our Price: $1,233.10
Free Shipping* | 30 Day Returns* | Authorized Dealer
Top VLX-TCW2V-C-B Specifications
  • HDMI Input: 1 HDMI 2.0/HDCP2.2
  • VGA/YPbPr Inputs: 1 15-Pin HD Female
  • HDMI Outputs: 1 HDMI 2.0/HDCP2.2
  • Compression: 8:1
"Custom Equipment w/ quick turnaround. CERTIFIED FRESH!"
Contact a product specialist!
Proudly supporting our customers since 2008

Description

Aurora introduces the VLX-TCM2V: a 4K UHD transceiver operating over Aurora's proprietary IPBaseT technology. IPBaseT technology combines AV and IP standards to create a synergized approach to streaming over IP. The VLX-TCM2V-C-B can serve as either the encoder or decoder. It produces 1.5 frame latency and visually lossless compression.

Ensure that you are set up for success to use this Aurora product: this transceiver wall plate requires a network switch that supports 1 Gbps, features IGMP and jumbo frame packets. Additionally, ensure that you are using CAT6a cable for high-quality performance. Other key features include the following:

  • 1080p to 4K, 4K to 1080p scaling
  • HDMI 2.0/HDCP 2.2
  • Secure Content Encryption
  • Unlimited scalability (based on network topology)
  • Video wall with image rotation
  • Power over Ethernet
  • Stereo line I/O
  • RS-232 and IR Control Ports
  • Auto sense switching
  • USB 2.0 Host and Device Ports
  • Dante IP audio option

Specifications

  • Latency: 1.5 Frames (25ms)
  • Scaling: 1080p to 4K, 4K to 1080p
  • Audio Analog: Stereo Line In/Out (3.5mm TRS)
  • 1G Copper Ethernet: RJ-45
  • LAN: RJ-45 10/100/1000M PoE (PSE)
  • Video Bandwidth: 340MHz
  • Video Support: Up to 4K2K 4:2:0 @60Hz
  • Audio Support: Up to 32 channels and break-away capable
  • RS-232: 2 qty Up to 115k Baud (3.5mm TRS)
  • IR: Bi-Directional (3.5mm TRS)
  • USB Connector: 1 USB 2.0 Type A, 1 USB 2.0 Type B 2 USB 1.1 Type A
  • Expansion Port: Dante Option
  • Interface: IR or Keypad via OSD, Webserver
  • Housing: Aluminum
  • Size: 2 gang
  • Dimensions: 3.728" x 2.83"(4.331" with tabs) x 1.404" Weight: 2.5 lbs
  • Mounting: Wall-mounting Decora 2 gang
  • Power Supply: 48V DC (2 pin Euro) or 1G PoE
  • Power Consumption: 9 Watts
  • Operation Temperature: 32~104F
  • Storage Temperature: -4~140F
  • Relative Humidity: 20~90% RH (no condensation)
