Kramer AV VSM-4x4HFS
4x4 HDMI Seamless Matrix Switcher and Multiviewer
- Modes: Matrix, video wall, dual, and quad
- Inputs: 4 HDMI
- Outputs: 4 HDMI
- Scaled HDMI outputs
Description
The Kramer VSM-4x4HFS is a 4x4 HDMI matrix switcher, it features 4 HDMI inputs and 4 scaled HDMI outputs. The switcher can also be used in video wall mode with bezel correction, 4 displays can look like 1 image. It can also be used as a multiviewer with Picture in Picture mode or even quad mode. The unit can handle resolutions up to 1080P with Deep Color and features seamless switching with zero transition time. The unit can be controlled via a wide range of applications including front panel, the included IR remote with OSD, RS-232, or over Ethernet with an integrated web browser. There are also 4 preset memory locations in each operation mode for commonly used settings.
The Kramer VSM-4x4HFS is a jack of all trades matrix that also offers seamless switching, 2x2 video wall support, and a mutliviewer for picture in picture, picture on picture, split and quad screen.
Specifications
- Video wall mode 2x2 with bezel correction
- Multiviewer: Split, PIP, POP, and quad screen
- Seamless switching
- Video adjustments: Color, hue, sharpness, noise, contrast and brightness
- Embedded HDMI HD audio
- Control: Front panel, IR remote, RS-232, or over Ethernet with an integrated web browser
- EDID management
- HDCP compliant
- Selectable aspect ratios
- Front panel lock out button for security
- Includes: Power cord, IR remote, rack ears
- Dimensions: 19" x 7" x 1U
- Weight: 6lbs
- Warranty: 7 years
