1:3 (U) Audio & Video Distribution Amplifier (BNCs)
Kramer's VM-30AVB is a compact designed 1x3 distribution amplifier for composite SDI video and unbalanced stereo audio signals. With high bandwidth of over 400MHz this device provides controls to compensate for signal losses that are inherent in long cable runs. With an array of uses this unit is primarily found in production/duplication facilities, however it is a great addition to any school, boardrooms or A/V system requiring high quality signal distribution at further lengths, for example retail stores, point of sale systems and CCTV/security environments.
Features of the VM-30AVB inlcude: RCA connectors for stereo audio signa;s, extra wide video bandwidth of 430Mhz that allows for high-resolution data/video signals, an audio level control knob, and on the front panel EQ (equalization) and video level controls. There is 1 video and 1 audio stereo input on the back panel, as well as 3 video and 3 audio stereo outputs, all video is through BNC connectors, and all audio is through RCA connectors. The compact desktop size of this device allows for 2 units to be rack mounted side-by-side in a 1U rack space, using an optional RK-1 19" rack adapter from Kramer. Comes with its own 12V DC power supply, brackets for stacking multiple units, and is backed by a 7 year warranty.
- Video Bandwidth: 430MHz
- Inputs: 1 SDI video on a BNC connector
- Outputs: 3 SDI Video on BNC connectors
- Audio Level Control and Level (gain) & EQ (peaking) Controls
- Audio Bandwidth: 100kHz
- Audio Input: 1 audio stereo on RCA connector
- Audio Outputs: 3 audio stereo on RCA connectors
- Coupling: AC
- Power Consumption: 12V DC
- Included Accessories: 12V DC power supply and brackets for stacking multiple units
- Warranty: 7 Years
