Lew Electric SWB-4

Square Four Power Floor Box w/ 4 Screw Plugs - Brass

In Stock!
Part #: SWB-4
Regular Price: $134.15
Instant Savings: -$26.83
Quantity: $107.32
0 out of 5 based on 0 ratings.

The Lew Electric SWB-4 is a floor box that holds (4) 15A tamper resistant power outlets, the top brass plate features four screw plugs. The box meets NEMA WD1-1983 heavy duty requirement for display receptacles, the box and outlets are UL listed. The box features a water tight assembly and includes a neoprene gasket. The box is adjustable and can accommodate any thickness floor up to 3/4".

***Included is a 4 port keystone plate in case you want to replace one of the power outlets***

To install use the included back box, there are twelve 3/4" conduit knockouts to bring your wire into.  The box may be attached directly to a sub floor or routed into finished floor. Brass screws are included to attach box to plate.

The Lew Electric SWB-4 is an economical solution when you need two duplex powers that is easy to install and functions perfectly.

  • Cover plate: 1/8" thick brass
  • Four 15A tamper resistant outlets
  • Four screw plug openings
  • Box dimensions: 5" X 5"
  • Depth: 4.01"
  • Water tight assembly
  • Outlet UL listing # 498
  • Outlet meets NEMA WD1-1983 heavy-duty requirement for display receptacle code
  • Box UL listing # 729A (File # E333616)
  • Cutout max dimensions: 4" x 3 1/2"
  • Includes back box, 4 port keystone plate, 1/16" neoprene gasket, and brass installation screws
  • Can accommodate any thickness floor up to 3/4"
  • Warranty: 6 months
