8x8 Seamless HDMI 1080P Matrix Switcher
The Intelix DIGI-88FS is an 8x8 HDMI matrix switcher, it has 8 HDMI inputs and 8 HDMI outputs. The HDMI outputs feature scaling up to 1920x1200 making it easy to install on non 1080P displays. This matrix switcher switches fast, seamless when outputs are scaled the same and less than half a second on scaled outputs. The matrix can be controlled via the front panel push buttons, IP (web GUI), RS-232, and IR. Up to 8 routing presets can be activated from the front panel. The DIGI-88FS can also be configured to automatically advance to the next HDMI input if the current video source is powered off.
The Intelix DIGI-88FS supports 1080P deep color 48 bit, HDCP, and embedded multi-channel audio. Also included is rack mount ears and an IR receiver for a hassle free installation.
- 8x8 HDMI matrix switcher
- Inputs: 8 HDMI
- Outputs: 8 HDMI
- Supports: supports 1080P deep color 48 bit, HDCP
- Embedded audio: Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master Audio
- Control: Front panel push buttons, IP (web GUI), RS-232, and IR
- HDMI cable distance: 16.4'
- Dimensions: 1.73 in. x 17.01 in x 10.67 in
- Weight: 8lbs
- Includes: Power cable, rack mount, and IR receiver
- Warranty: 2 years
