6x2 HDMI 4K Fast Switching Matrix Switcher w/ HDMI 2.0
The Gefen GTB-HD4K2K-642-BLK is a small form factor 6x2 HDMI matrix switcher, it features 6 HDMI inputs and 2 HDMI outputs that are capable of resolutions up to 4K. Also included are two Toslink audio outputs for connecting to your rooms amplifier. The matrix switches fast and with no artifacts so there is no lag time switching your inputs and outputs. The matrix features 12-bit Deep Color, 3D, multi-channel audio, EDID, and support for HDMI 2.0 and HDCP 1.4. The unit can be controlled via the front panel push buttons, the included IR remote control, RS-232, or over IP using TCP/IP or the integrated web server.
You can visually see your routing status with LED indicators on the unit, as well as audio and EDID indicators. The unit is surface mountable and includes a locking power supply for reliability. The Gefen GTB-HD4K2K-642-BLK is extremely affordable and a reliable way to distribute your HDMI, as well as send your audio to an amplifier if needed.
- 6x2 HDMI 4K matrix switcher
- Video inputs: 2 HDMI
- Video outputs: 2 HDMI
- Audio outputs: 2 Toslink
- Resolution: Up to Ultra HD 4K at 60Hz 4:2:0 or 30Hz 4:4:4, 4K Cinema (DCI) at 24Hz or 30Hz 4:4:4, and 1080p Full HD
- Control: Front panel push buttons, the included IR remote control, RS-232, or over IP using TCP/IP or the integrated web server
- Audio: LPCM 7.1, Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio
- HDMI 2.0 compliant
- HDCP 1.4 compliant
- Deep Color up to 12-bit at 1080P
- 3D and lip sync pass through
- EDID management
- LED indicator lights
- Fast switching technology
- Surface mountable
- Dimensions: 6.9" x 11.9" x 1.0"
- Weight: 4lbs
- Includes: Locking power supply, IR remote, DB-9 cable
- Warranty: 2 years
