1x8 HDMI Distribution Amplifier, HDCP 2.2, 4K60, 10.2Gbps
The Comprehensive CDA-HD820EK 1x8 HDMI Distribution Amplifier comes with high quality 4K60 resolutions, HDCP 2.2 compliance, and bandwidth speeds up to 10.2Gbps. It allows the user to connect and distribute one HDMI input simultaneously to up to eight separate HDMI outputs. This splitter has Smart EDID control which provides the option to choose between STD (fixed) or TV (downstream) settings. The slim and compact design makes this metal enclosed unit an ideal solution in a variety of different settings. It is perfect for applications in lecture halls, conference rooms, as well as showroom and retail displays. This CDA-HD820EK distribution amplifier from Comprehensive is backed by a two year warranty.
- Inputs: 1x HDMI
- Outputs: 8x HDMI
- Video Resolutions: 480i to 4K60 (YUV420)
- Video Bandwidth: 300MHz/10.2Gbps
- Power Supply: 5V/1A DC
- Power Consumption: 2W(Max)
- ESD Protection: ~8kV (air-gap discharge) ~4kV (contact discharge)
- Chassis Material: Metal
- Silkscreen Color: Black
- Weight: 0.52 lb.
- Dimensions(WxDxH): 11.10" x 3.10" x 0.66"
- Included Accessories: Power Adapter, Operation Manual
- Warranty: 2 Years
