4x1 HDMI Video/Audio Switcher - IR Remote, RS-232, HDCP
The ATEN VS481A is a 4x1 HDMI 1.3 Video/Audio Switcher that offers HDCP 1.4 compliance and RS-232 control. This device gives users the ability to quickly and efficiently share up to four HDMI A/V sources to be connected to one HDMI display. The 4-port switch allows convenient switching between digital devices such as DVD players, satellite receivers, digital camcorder, and more. The unit will support up to 1080p HDTV and 1920 x 1200 WUXGA PC resolutions, with long distance transmission ranges up to 49'. It allows you to select the desired input source via a remote control unit and push buttons located on the switch.
- Inputs: 4 x HDMI Type A Female
- Output: 1 x HDMI Type A Female
- Supported Resolutions: up to 1080p
- Bandwidth: 6.75Gbps (2.25 Gbps per lane)
- Max Video Distance: 49'
- Compliance: HDMI (3D, Deep Color), HDCP 1.1, CEC
- Audio Inputs: 4 HDMI
- Audio Outputs: 1 HDMI
- Control: RS-232, 1 DB-9 Connector
- Power Connector: DC Jack
- Power Consumption: 5V DC, 2.4W
- Housing Material: Metal
- Dimensions (LxWxH): 7.87 x 3.26 x 0.98"
- Weight: 1.04lbs
- Included Accessories: HDMI Cable, IR Remote Control, Power Adapter, User Manual, Quick Start Guide
- Warranty: 3 Years
