1X4 HDMI Distribution Amplifier 4K60 4:2:0 - HDCP Compatible
The VS184A 1X4 HDMI 4K60 4:2:0 Distribution Amplifier from ATEN is HDCP compatible and it supports all HDMI-enabled equipment (DVD players, satellite set-top boxes, etc). This distribution amplifier is perfect for splitting one digital high definition video source to four HDMI displays at one time. No software installation is required for this device, it is plug-and-play making it a simple set-up for the user. It is an effective solution for many scenarios, such as home theater applications, as well as corporate, educational and commercial settings.
- Input: 1 x HDMI Type A Female, Max Distance 5.9'
- Output: 4 x HDMI Type A Female
- Resolution: Up to 4096x2160 / 3840x2160 @ 60Hz (4:2:0), 4096x2160 / 3840x2160 @ 30Hz (4:4:4)
- Data Rate: 10.2 Gbps (3.4 Gbps Per Lane)
- Max. Pixel Clock: 340 MHz
- Compliance: HDMI (3D, Deep Color, 4K)
- HDCP 1.4 Compatible
- Max Distance: Up to 49.2'
- Audio Input: 1 x HDMI Type A Female
- Audio Output: 4 x HDMI Type A Female
- Power Connectors: 1 x DC Jack
- Power Consumption: 5.3 VDC, 4.6W
- Included Accessories: Power Adapter, HDMI Cable, User Instructions
- Housing: Metal
- Weight: 1.04 lbs.
- Dimensions (LxWxH): 7.87" x 3.15" x 0.98"
- Warranty: 3 years
