ATEN VE601R

DVI HDBaseT-Lite Extender (Receiver)

Satisfaction Guaranteed!
Part #: VE601R
Regular Price: $231.25
Instant Savings: -$46.25
Quantity: $185.00
0 out of 5 based on 0 ratings.

The VE601R from ATEN is a DVI HDBaseT-Lite Receiver, that has been designed to accept DVI video signals up to 229' in distance from a compatible transmitter unit over Ethernet cable at 10.2Gbps. Using HDBaseT technology this kit will even support 1920 x 1200 media up to 131' away, thus offering a simple, adaptable, and cost effective solution for Pro Audio Video installation. Making this unit a perfect solution for A/V installations that require video signal interference protection, such as in medial and military installations. It comes in a easy to mount design, offers a slip resistant DC jack locking mechanism, and can be installed virtually anywhere while ensuring great product performance reliability.

  • Receiver Connections: Inputs: HDBaseT / Outputs: DVI-D
  • Bandwidth: 10.2Gbps
  • Max Resolution Range: 1920x1200 114' (Cat 5e/6) / 131' (Cat 6a) / 1080p@ 196' (Cat 5e/6) / 229' (Cat 6a)
  • Compliance: DVI (3D, Deep Color), HDCP Compatible
  • Max Pixel Clock: 340 MHz
  • HDBaseT Anti-Jamming resists signal interference during video transmission using HDBaseT technology
  • Rack-Mountable
  • Power Connectors: DC locking jack
  • Receiver Power Consumption: 5V DC, 1.85W
  • Weight: 0.55lbs
  • Dimensions (L x W x H): 4.02 x 3.43 x 1.18"
  • Included Accessories: Power Adapter for each unit
  • Warranty: 3 Years
