Metreau 7-Button Keypad w/ Carrier for HydraPort HPX Series
The HPX-U400-MET-7 by AMX. This module is a Metreau 7-Button keypad (Standard buttons include TUNER, DVD, LIGHTS, FAN, BLINDS, DISPLAY, and +/-) in a carrier that allows it to be installed into the HydraPort chassis. This model is specifically made for use on Boardrooms, conference rooms, meeting rooms or auditoriums where equipment is permanently installed in the room and users must connect to that equipment from a conference table or lectern.
- 4.5 HydraPort Units
- FRONT PANEL COMPONENTS:
- 7 tactile pushbuttons with blue LED indicators that illuminate when pressed to confirm the source/function was selected and that it is currently being used. These pre-printed buttons are field-replaceable. The bottom button functions as 2 buttons - there are 2 positions (left and right) that allow the user to control channel/levels (up/down).
- Blue LEDs indicate activity
- REAR PANEL COMPONENTS
- DIP switch - 8 position mini dip switch used to set the device address for the keypad on the AxLink Bus
- AxLink connector - Wiring - 4-pin 3.5mm Phoenix AxLink connector
