Atlona AT-HDDA-8
1x8 HDMI 4K Distribution Amplifier w/ Audio De-embedding

Description

The Atlona AT-HDDA-8 is a 1x8 HDCP compliant HDMI distribution amplifier that is capable of 4K resolution, it supports Dolby TrueHD, DTS-HD Master Audio, and 3D up to 36-bit Deep Color.  Up to 4 units can be cascaded together, and the HDMI and power ports are locking for easy and reliable installation.  There is also analog and digital audio de-embedding in case you need to connect to an external amplifier, this is done via S/PDIFF for digital and 5-pin balanced terminal block for analog.

There is also EDID management and the unit can learn what the first connected output displays and copy that over to the rest of the outputs so everything is correct.  There are LED lights on the front for source and output status.  Included are rack mount ears that can be used for rack or even wall mounting. With the industry leading 10 year warranty and an affordable price you can't go wrong.

Specifications

• Chroma Subsampling: 4:4:4, 4:2:2, 4:2:0 (UHD only)
• Analog and digital audio de-embedding
• Supports Dolby TrueHD, DTS-HD Master Audio, and 3D up to 36-bit Deep Color
• Colorspace: RGB, YCbCr 4:4:4, YCbCr 4:2:2 Bandwidth: 10.2Gbps
• EDID management
• LED link status on front
• HDCP Compliant
• HDMI in distance: Up to 50' at 1080P 8 bit
• HDMI out distance: Up to 50' for 1080p at 12 bit
• HDMI out distance: Up to 15' for 4K
• Dimensions: 1.73 x 17.08 x 10.04
• Weight: 6.13lbs
• Includes: Rack ears and power supply
• Warranty: 10 years

Downloads

• Atlona AT-HDDA-8 Specifications (PDF)
• Atlona AT-HDDA-8 Manual (PDF)
